Glass Centrifuge Tubes

Photo of Corning 8060 PYREX® Conical Centrifuge Tubes with Beaded Rim

Uniform glass distribution in the wall taper and bottom provides improved mechanical strength prevents the formation of failure causing stress regions during centrifuging and insures the highest degree of accuracy.

Photo of Corning 8084 PYREX® Conical Centrifuge Tube with White Graduations and Standard Taper Pennyhead Stopper

These tubes have white enamel graduations. The 5 and 15mL sizes are graduated upward from the tip in 0.1mL divisions. The 50mL size is graduated upward from tip to 10mL in 0.5mL divisions and from 10 to 50 in 1mL divisions. The pennyhead stopper is solid.

Photo of Corning 8120-12 PYREX® 12mL Heavy Duty Conical Centrifuge Tube with Beaded Rim

These 12mL heavy duty PYREX® conical centrifuge tubes are made to the same O.D. and length specifications as No. C1880, but with increased wall thickness for greater mechanical strength. In order to conform to outside diameter and overall length limitations imposed by centrifuge rotors and supports, it has been necessary to reduce the capacity these heavy duty tubes.

Photo of Corning 99502-5 PYREX® 5mL Disposable Glass Conical Centrifuge Tubes without Screw Caps

These disposable Pyrex® glass centrifuge tubes are manufactured from Type I borosilicate glass and have GPI threads. They are supplied without caps. The tubes are designed to withstand centrifugation up to 3,000 RCF and are packed in convenient, easy to use packs, which are shrink-sealed for protection during shipment. For reusable phenolic screw caps with white rubber liners, see No. 9999, for reusable phenolic screw caps with Polytetrafluorethylene (PTFE) faced rubber liners see No.

Photo of Corning 8080 PYREX® Conical Centrifuge Tube with White Graduations and Beaded Rim

These tubes have white enamel graduations. The 10 and 15mL sizes are graduated upward from tip in 0.1mL divisions. The 50mL size is graduated upward from tip to 10mL in 0.5mL divisions and from 10 to 50mL in 1mL divisions.

Photo of Corning 8101 PYREX® Conical Centrifuge Tubes with Black Graduations and Beaded Rim

These tubes have sharp black enamel graduations and markings. They have precision formed tips and uniform walls throughout for a high degree of accuracy and mechanical strength.

Photo of Corning 8140 PYREX® Heavy Duty Conical Centrifuge Tube with White Graduations and Beaded Rim

These heavy duty PYREX® conical centrifuge tubes have durable white enamel graduations and are made to the same O.D. and length specifications as C1880, but with increased wall thickness for greater mechanical strength. In order to conform to outside diameter and overall length limitations imposed by centrifuge rotors and supports, it has been necessary to reduce the capacity these heavy duty tubes. The 12mL size is graduated upward from tip in 0.1mL divisions. The 40mL size is graduated upward from tip in 0.5mL divisions to 10mL and from 10 to 40mL in 1mL divisions.

Photo of Corning 8082 PYREX® Conical Centrifuge Tubes with White Graduations and Screw Caps

These tubes have white enamel graduations. The 15mL size is graduated upward from the tip in 0.1mL divisions. the 50mL size is graduated upward from tip to 10mL in 0.5mL divisions and from 10 to 50mL in 1mL divisions. The phenolic screw cap is fabricated of a resin which is specially formulated to resist the effects of temperature and steam. Caps have a glued-in white rubber liner.

Photo of Corning 8142-10 PYREX® 10mL Conical Heavy Duty Centrifuge Tubes with Screw Cap

This heavy duty 10mL PYREX® conical centrifuge tube is made with increased wall thickness for greater mechanical strength. In order to conform to outside diameter and overall length limitations imposed by centrifuge rotors and supports, it has been necessary to reduce the capacity of these heavy duty tubes. The 10mL tube is graduated with durable white enamel upward from the tip in 0.1mL divisions.

Photo of Kimble 45194-12 KIMAX 12mL Conical Bottom Heavy-Duty Centrifuge Tube with Beaded Rim

Standard taper KIMAX centrifuge tube. Made with heavier walled tubing to withstand higher centrifugation speeds. Top is beaded for strength.

(Sample Photo Displayed. Individual items may differ from the image shown.)



Photo of Kimble 45210 KIMAX Heavy-Duty Graduated Centrifuge Tubes with Pennyhead Stopper

Kimble 45210 KIMAX Heavy-Duty Graduated Centrifuge Tubes with Pennyhead Stopper. Standard taper KIMAX tube is a heavy-duty centrifuge tube, calibrated to contain. Scale, legend and marking spot are durable white ceramic enamel. Tooled for a stopper, which is included. (Do not centrifuge with stopper in tube)

(Sample Photo Displayed. Individual items may differ from the image shown)



Photo of Kimble 45243-200 KIMAX® 100mL 6" Short Cone Oil Centrifuge Tube with 0-200% Graduations

Kimble 45243-200 KIMAX® 100mL 6" Short Cone Oil Centrifuge Tube with 0-200% Graduations is designed for field use in testing petroleum. 6" short cone tube is calibrated to contain and is graduated in % (100 mL equals 200%). Scale and legend are durable white ceramic enamel. Also referenced in ASTM D4007. Top is tooled to accept a Snap Cap (28150-6).

(Sample Photo Displayed. Individual items may differ from the image shown.)



Photo of Kimble 45244-100 KIMAX® 100mL BS & W Oil Centrifuge Tube with 1.5 mL Graduated Stem

Kimble 45244-100 KIMAX® 100mL BS & W Oil Centrifuge Tube with 1.5 mL Graduated Stem is used in the determination of bottom sediment and water (BS & W) in petroleum products and in the determination of foots in raw linseed oil by the gravimetric method (ASTM D1966). Calibrated to contain. Stem diameter holds 1.5 mL. Scale and legend are durable white ceramic enamel.

(Sample Photo Displayed. Individual items may differ from the image shown.)



Photo of Kimble 45244-200 KIMAX 0-200% Graduated BS & W Tube, 100mL

Kimble 45244-200 KIMAX 0-200% Graduated BS & W Tube, 100mL. Used in the determination of bottom sediment and water in petroleum products and in the determination of foots in raw linseed oil by the gravimetric method (ASTM D1966). Calibrated to contain. Stem diameter holds 1.5 mL (0-3%). Scale and legend are durable white ceramic enamel.

(Sample Photo Displayed. Individual items may differ from the image shown.)



Photo of Kimble 45243-100 KIMAX® 6" Short Cone Oil Centrifuge Tube

Kimble 45243-100 KIMAX® 6" Short Cone Oil Centrifuge Tube is designed for field use in testing petroleum. Calibrated to contain. Scale and legend are durable white ceramic enamel. Also referenced in ASTM D4007. Top is tooled to accept a Snap Cap (28150-6)

(Sample Photo Displayed. Individual items may differ from the image shown.)



Photo of Kimble 45212 KIMAX Glass Round Bottom Centrifuge Tubes with Screw Caps, Heavy Duty

Kimble 45212 KIMAX Glass Round Bottom Centrifuge Tubes with Screw Caps are useful in separating neutralized sediment for culturing from specimens of sputum. Will be found useful also for other clinical work and in many microbiological applications. Made with a heavy wall to withstand higher speeds in centrifuging. Marking spot is sandblasted. Autoclavable black phenolic caps with PTFE-faced rubber liners are supplied unattached.  Replacement cap is 45066C-24.

Photo of Kimble 45196 KIMAX Heavy-Duty Plain Centrifuge Tubes with Screw Caps

Standard taper conical bottom KIMAX centrifuge tube is made with heavier walled tubing to withstand higher centrifugation speeds. Top has screw thread finish. Cap with rubber liner is included but not attached. Replacement cap is 45066B.

(Sample Photo Displayed. Individual items may differ from the image shown)



Photo of Kimble 45199 KIMAX Heavy Duty Graduated Centrifuge Tubes with Conical Bottom

Standard taper KIMAX tube is a heavy-duty version of Kimble 45165. Made with heavier walled tubing to withstand higher centrifugation speeds. Top is beaded for strength. Graduated and calibrated to contain. Scale is white ceramic enamel.

(Sample Photo Displayed. Individual items may differ from the image shown)



Photo of Kimble 73790 KIMAX Disposable Glass Centrifuge Tubes with Snap Cap Finish

Kimble 73790 KIMAX Disposable Glass Centrifuge Tubes with Snap Cap Finish are made from borosilicate glass and are ungraduated. Conical shaped bottoms on the 5, 10, and 15 mL sizes and a bullet-nosed shape on the 50 mL size to withstand centrifugation up to 2980 RCF. The 5, 10, and 15 mL sizes have a finished top for a snap-cap closure. The 50 mL size has a tooled top. Tubes are plastic shrink wrapped in modular trays to keep them clean and safe in transit. Snap-cap closures are not supplied. See 73837 for snap cap closures

Photo of Kimble 45200 KIMAX Heavy-Duty Conical Centrifuge Tubes with Graduations and Screw Caps

Kimble 45200 KIMAX Heavy-Duty Conical Centrifuge Tubes with Graduations and Screw Caps. Graduated and calibrated to contain. Scale is durable white ceramic enamel. Made with heavier walled tubing to withstand higher centrifugation speeds. Top has a screw thread finish.  Autoclavable screw-thread cap with PTFE-faced rubber liner is included but not attached. Replacement cap is 45066C.

(Sample Photo Displayed. Individual items may differ from the image shown)
